LED Dimming Compatibility

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	A	11.6%
Unison DRd w/ ELV10 Module	B	1.5%
Unison DRd w/ Phase Adept Module (LED10)*	A	7.4%
Echo Phase-Adapative Dimmer (ELVD)	B	15.4%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	A	0.7%
Foundry Phase-Adaptive Dimmer (UFD)	B	13.5%
Sensor3 w/ D20 Module	A	14.1%
Sensor3 w/ ELV10-S Module	A	14.8%
Sensor3 w/ Phase Adept Module (LED10)*	A	17.8%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	NR	--
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	B	10.6%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	B	29.3%
Unison DRd w/ ELV10 Module	B	4.4%
Unison DRd w/ Phase Adept Module (LED10)*	B	31.5%
Echo Phase-Adapative Dimmer (ELVD)	B	15.3%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	B	5.1%
Foundry Phase-Adaptive Dimmer (UFD)	B	13.5%
Sensor3 w/ D20 Module	B	29.1%
Sensor3 w/ ELV10-S Module	B	28.3%
Sensor3 w/ Phase Adept Module (LED10)*	B	27.4%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	NR	--
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	B	40.1%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	A	45.3%
Unison DRd w/ ELV10 Module	A	45%
Unison DRd w/ Phase Adept Module (LED10)*	A	46.6%
Echo Phase-Adapative Dimmer (ELVD)	A	26.1%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	A	25.3%
Foundry Phase-Adaptive Dimmer (UFD)	A	35.9%
Sensor3 w/ D20 Module	A	39.7%
Sensor3 w/ ELV10-S Module	A	33.8%
Sensor3 w/ Phase Adept Module (LED10)*	A	27.9%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	A	77.8%
Legacy Unison DR w/ ELV10 Module	A	59.7%
Legacy Unison DR w/ Phase Adept Module (LED10)*	A	9.9%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	A	53%
Unison DRd w/ ELV10 Module	A	53.5%
Unison DRd w/ Phase Adept Module (LED10)*	A	48.4%
Echo Phase-Adapative Dimmer (ELVD)	A	40.4%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	A	35.3%
Foundry Phase-Adaptive Dimmer (UFD)	A	41.3%
Sensor3 w/ D20 Module	A	44.2%
Sensor3 w/ ELV10-S Module	A	46.5%
Sensor3 w/ Phase Adept Module (LED10)*	A	47.9%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	A	72.7%
Legacy Unison DR w/ ELV10 Module	A	71.8%
Legacy Unison DR w/ Phase Adept Module (LED10)*	A	49.9%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	B	40.8%
Unison DRd w/ ELV10 Module	B	21%
Unison DRd w/ Phase Adept Module (LED10)*	B	42.3%
Echo Phase-Adapative Dimmer (ELVD)	B	31.5%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	B	33.8%
Foundry Phase-Adaptive Dimmer (UFD)	B	17.9%
Sensor3 w/ D20 Module	B	35.8%
Sensor3 w/ ELV10-S Module	B	13.7%
Sensor3 w/ Phase Adept Module (LED10)*	B	5.5%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	B	44.4%
Legacy Unison DR w/ ELV10 Module	B	59.2%
Legacy Unison DR w/ Phase Adept Module (LED10)*	C	7.1%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	B	1.5%
Unison DRd w/ ELV10 Module	B	6%
Unison DRd w/ Phase Adept Module (LED10)*	B	6.3%
Echo Phase-Adapative Dimmer (ELVD)	B	7.6%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	B	7.6%
Foundry Phase-Adaptive Dimmer (UFD)	B	5.7%
Sensor3 w/ D20 Module	B	3.5%
Sensor3 w/ ELV10-S Module	B	9.9%
Sensor3 w/ Phase Adept Module (LED10)*	B	8.9%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	B	5.6%
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	B	16.2%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module		--
Unison DRd w/ ELV10 Module		--
Unison DRd w/ Phase Adept Module (LED10)*		--
Echo Phase-Adapative Dimmer (ELVD)		--
Echo Relay Panel Phase-Adapative Dimmer (ERP)		--
Foundry Phase-Adaptive Dimmer (UFD)		--
Sensor3 w/ D20 Module		--
Sensor3 w/ ELV10-S Module		--
Sensor3 w/ Phase Adept Module (LED10)*		--
DRd WorksRight		--
Legacy Unison DR w/ D20 Module		--
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*		--
DRd 0-10V Option Card	B	6.6%
ERP 0-10V Option Card	B	6.6%
ELD	B	6.7%
Response 0-10V Gateway	B	6.9%
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	B	0.2%
Unison DRd w/ ELV10 Module	B	0.6%
Unison DRd w/ Phase Adept Module (LED10)*	B	0.4%
Echo Phase-Adapative Dimmer (ELVD)	B	0.2%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	B	0.1%
Foundry Phase-Adaptive Dimmer (UFD)	B	0.3%
Sensor3 w/ D20 Module	B	0.4%
Sensor3 w/ ELV10-S Module	B	0.5%
Sensor3 w/ Phase Adept Module (LED10)*	B	0.5%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	B	0.4%
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	B	1.3%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	A	62.3%
Unison DRd w/ ELV10 Module	A	61.2%
Unison DRd w/ Phase Adept Module (LED10)*	A	54.5%
Echo Phase-Adapative Dimmer (ELVD)	A	48.3%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	A	40.3%
Foundry Phase-Adaptive Dimmer (UFD)	A	44.9%
Sensor3 w/ D20 Module	A	44.2%
Sensor3 w/ ELV10-S Module	A	48%
Sensor3 w/ Phase Adept Module (LED10)*	A	49.4%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	A	91.4%
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	A	38.5%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

The following table provides a summary of results with ETC power control products. An entry of "--" indicates the fixture was not tested with ETC product. Detailed descriptions for the fade performance grades is available below the results chart. For complete testing details, click the "See Full Report" button.

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
Unison DRd w/ D20 Module	A	36%
Unison DRd w/ ELV10 Module	A	35.4%
Unison DRd w/ Phase Adept Module (LED10)*	A	48.5%
Echo Phase-Adapative Dimmer (ELVD)	A	35.1%
Echo Relay Panel Phase-Adapative Dimmer (ERP)	A	30%
Foundry Phase-Adaptive Dimmer (UFD)	A	32%
Sensor3 w/ D20 Module	A	33.5%
Sensor3 w/ ELV10-S Module	A	32.4%
Sensor3 w/ Phase Adept Module (LED10)*	A	33.9%
DRd WorksRight		--
Legacy Unison DR w/ D20 Module	A	66.9%
Legacy Unison DR w/ ELV10 Module		--
Legacy Unison DR w/ Phase Adept Module (LED10)*	A	34.3%
DRd 0-10V Option Card		--
ERP 0-10V Option Card		--
ELD		--
Response 0-10V Gateway		--
Foundry UFR2-LV		--
DRd D20F		--
DRd DALI		--
ERP DALI		--
Mosaic DALI		--
DRd AD20		--
DRd AELV5		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
DMX		--

Results:

Dimmer/Control	Fade Performance	Min Stable Level
F-Drive CC		--
F-Drive CV		--
ArcSystem D4 CC		--
ArcSystem D4 CV		--

* added when available

Fade Performance Grade
A	Smooth and continuous dimming (up and down) through the entire dimming range; no noticeable bump when fading to or from off.
B	Smooth and continuous dimming (up and down) through the entire dimming range; minimally noticeable but not disruptive bump when fading to or from off. Acceptable bump is based on the specified minimum level of the driver or fixture.
C	Minor stepping during fading (up or down) or noticeable bump (outside of specified fixture or driver range) when fading to or from off.
D	Inconsistent or irregular fade performance, but otherwise compatible.
NR	Does not fade or is incompatible with the dimmer.

LED Dimming Compatibility

Showing results 1 through 10 of 269
