Table Properties

The Table control is used to define an area of the touchscreen configuration that a Paradigm Central Control Server (P-CCS) will populate with Net3 lighting system errors from supported Net3 products.

Touching the table will cause a manual refresh of that data. Currently this control type is only supported by the Paradigm Virtual Touchscreen, which requires a Paradigm Central Control Server (P-CCS) system to operate.

A table widget has the following editable properties in addition to the Basic Properties:

• Text Font - the font used to display the text on the number edit label
• Text Color - the color of the numerical text displayed on the date label
• Text Alignment - the vertical and horizontal alignment of the numerical text displayed on the date label
• Text Size - the height of the text (in pixels) of the numerical text displayed on the date label
• Bold - a "Yes" or "No" setting used to bold the numerical text on the date label
• Italic - a "Yes" or "No" setting used to emphasize the numerical text on the date label

Reference Control Properties for instructions to configure each property.
