Hoists


  • Want to learn more about our automated rigging systems?

    Complete this form and a member of our team will be in touch!

    REQUEST A DEMO



    • Download ETC Rigging brochure

      Download


  • Hoist Comparison FlyPipe FlyPipe Studio P2 - 300/600/900 P1 EXO P75 NXT
    Wire rope size Dual 1/8” 3.1 mm Dual 1/8” 3.1 mm 3/16”
    5 mm     		3/16”
    5 mm     		3/16”
    5 mm    		 1/4”
    6.3 mm     		3/16”
    5 mm
    Max. number of lines 6 TwinLine pairs 2 TwinLine pairs 8 8 8 8 7
    Min. number of lines 2 TwinLine pairs 2 TwinLine pairs 2 3 - 5 3 - 5 3 - 7 3 - 5
    Underhung ✓ ✓ ✓ ✓ ✓ ✓ ✓
    Upright ✓ ✓ ✓ ✓
    Vertical ✓ ✓ ✓ ✓
    Prodigy cable management support ✓ ✓ ✓
    Pantograph cable management support ✓ ✓ ✓ ✓ ✓
    Helix cable management support ✓ ✓ ✓ ✓ ✓ ✓ ✓
    Swag cable management support ✓ ✓ ✓ ✓ ✓ ✓ ✓
    Compression Tube support ✓ ✓ ✓
    Slack line detection SmartSlack SmartSlack ✓ ✓ ✓ ✓ ✓
    Load cell ✓ ✓ ✓ ✓ ✓
    Lift distance 50 ft
    15 m    		 23 ft
    7 m    		 50 ft
    15 m    		 50 ft
    15 m    		 50 ft
    15 m    		 75 ft
    23 m    		 62 ft / 100 ft
    19 m / 30 m
    UL/ETL UL UL UL UL UL UL UL
    DGUV 17/18 600 & 900 only
    Lifting capacity 500 lb
    225 kg    		 300 lb
    136 kg    		 650 lb
    300 kg/600 kg/900 kg    		 900-2000 lb
    400-900 kg    		 900-2000 lb
    400-900 kg    		 1200-3300 lb
    540-1500 kg    		 800-2000 lb
    500-900 kg
    Secondary load arrest device SafeStop SafeStop Self-locking gearbox
    (for 300 only)    		 Electro-mechanical Electro-mechanical Electro-mechanical Mechanical
    Soft Start/Stop Standard Standard Optional Optional Optional Optional Standard
    Fixed speed (208V/60Hz) 20 fpm
    10 cm/s    		 20 fpm
    10 cm/s    		 23 fpm
    12 cm/s    		 30 fpm
    15 cm/s    		 30 fpm
    15 cm/s    		 15 / 20 fpm
    7 / 10 cm/s    		 20 fpm
    10 cm/s
    Fixed speed (400V/50Hz) 20 fpm
    10 cm/s    		 20 fpm
    10 cm/s    		 20 fpm
    10 cm/s    		 30 fpm
    15 cm/s    		 - - 0-180 fpm
    0-0.9 m/s
    Fixed speed (480V/60Hz) 20 fpm
    10 cm/s    		 20 fpm
    10 cm/s    		 25 fpm
    13 cm/s    		 30 fpm
    15 cm/s    		 30 fpm
    15 cm/s    		 20 fpm
    10 cm/s    		 -
    Variable speed - - - 0-180 fpm
    0.9 m/s    		 0-180 fpm
    0.9 m/s    		 0-180 fpm
    0.9 m/s    		 0-180 fpm
    0.9 m/s
