Gio @5

  • S P E C I F I C A T I O N S


    FEATURES

    • 2,048 to 32,768 outputs upgradeable in 1024, 2048 or 4096 increments
    • 16,000 Control Channels (devices)
    • 10,000 Cues
    • 999 Cue Lists and Submasters
    • 200 Active Playbacks
    • 999 Submasters
    • 100 Fader Pages
    • 4 x 1,000 Palettes (Intensity, Focus, Color, Beam)
    • 1,000 Presets (all palette)
    • 1,000 Groups
    • 1,000 Effects (relative, absolute or step)
    • 99,999 Macros
    • 1,000 Snapshots
    • 1,000 Curves
    • 1,000 Color Paths
    • 12 discrete users
    • Partitioned control
    • Show import from Obsession, Express™, Expression®, Emphasis®, Congo®, Cobalt®, Grand MA1, Grand MA2, Safari and Strand 500/300 Series
    • Virtual Media Server function for pixel-mapped effects, images and animations
    • Support for multiple languages, including English, German, Spanish, French, Italian, Japanese, Korean, Russian and Chinese (Simplified and Traditional)

    HARDWARE

    • Master playback pair with motorized 60mm faders
    • ETCNet2, Net3 (powered by ACN), ArtNet and Avab UDP output protocols
    • Five 60mm motorized faders x 100 pages for configurable Cue Lists, Submasters, grand masters, IFCB Palette/Presets lists or individual instances
    • Supports two external display port monitors at 1280 x 1024 (minimum resolution required with optional touch or multitouch control)
    • One 17.3 inch multi-touch LCD touchscreen for display, direct selection and context-sensitive control
    • Four force-feedback encoders for non-intensity parameter control
    • Configurable high-density channel display, with format and flexi-channel modes
    • Two individually configurable Ethernet ports
    • Solid-state hard drive
    • 11 USB ports for flashdrives, pointing devices, keyboards
    • Multiple MIDI and/or SMPTE TimeCode Inputs, MIDI In and Out, Analog/Serial Inputs, OSC transmit/receive through Show Control and I/O gateways

    PHYSICAL

    Gio @5 Dimensions*
    MODEL HEIGHT WIDTH DEPTH
    inches mm inches mm inches mm
    Gio @5 14.33 364 25.25 641 26.25 67
    Gio @5 in shipping container 13.50 342 30.25 769 30.50 775
    Gio @5 in roadcase 11.50 292 30.75 781 32 813

    Gio @5 Weights*
    MODEL WEIGHT
    lbs kgs
    Gio @5 console 52.0 23.59
    Gio @5 in shipping container 61.0 27.67
    Gio @5 in roadcase 93.75 42.52

    *Weight and dimensions typical





    ORDERING INFORMATION
    Gio @5
    MODEL DESCRIPTION
    Gio @5 – 2K Gio @5 console, 2,048 outputs (minimum)
    Gio @5 – 32K Gio @5 console, 32,768 outputs (maximum)
    Ion RPU – 2K Ion Remote Processor Unit, 2,048 outputs
    Eos RPU3 – 32K Eos Remote Processor Unit, 32,768 outputs
    Eos 1000 Up 1,024 output upgrade
    Eos 2000 Up 2,048 output upgrade
    Eos 4000 Up 4,096 output upgrade
    ETCnomad 256 Client for PC/Mac

    Output protocols are distributed using ETCNet2 DMX Nodes or Net3 DMX/RDM Gateways. I/O Gateways and Show Control Gateways provide switch closure functionality, MIDI and SMPTE TimeCode.

    Gio @5 Accessories
    MODEL DESCRIPTION
    Net3 RFR – US Radio Focus Remote 903 MHz US
    Net3 RFR – RX Net3 Radio Focus Remote, receiver only
    Net3 RFR – TX Net3 Radio Focus Remote, transmitter only
    FADW 2x10 Fader Wing - 2x10
    FADW 2x20 Fader Wing - 2x20
    Eos MFW10 Eos Motorized Fader Wing 10
    Eos MFW20 Eos Motorized Fader Wing 20
    Net3 RVI Net3 Remote Video Interface
    Net3 RVI3 Remote Video Interface
    GIO @5 – FC Gio @5 Flightcase

    Eos Family Offline Editor software for Mac and PC platforms is now called ‘ETCnomad’ and is available for download from www.etcconnect.com

    Gio @5 requires Windows 7 compatible external monitors, 1280x1024 minimum resolution, standard, touch or multi-touch

    SHIPS WITH:
    • Dust cover
    • One Littlite
    • Mouse and mousepad
    • Backlit alphanumeric keyboard
    • Two active display port to DVI adapters
    • Locking IEC power cord
